Features

1. Wide Range Output : DC output 0~80V/128A to 0~1500V/6.8A

2. Wide Range Input : Max. : AC mains 85~305V (47~63Hz), Rating : 100V~277Vac (50/60Hz)

3. Power Regulated by Input Voltage : AC180~305V(3.4kW) ; AC90~132V(1.5kW)

4. True parallel operation allows the master unit to set and display the total output current.
5. Internal clock rate synchronization reduces electromagnetic interference, enhancing system.
   stability and overall efficiency.
6. Built-in patented synchronizing circuitry allows easy integration of 32 units.
7. High Active Power Factor Correction. Totem-Pole PFC design, PF > 0.99
8. Efficiency has nearly 95%. (each stage PFC, D2D, BUCK > 98%)



 Electrical

1. 400kHz switching frequency for extremely low output ripple and noise.
2. Multiple 32 bit ARM-based embedded system, enabling fast boot time of less than 10 seconds.
3. Use Wide Bandgap power semiconductors (SiC MOSFET SBD) for better performance and higher
   efficiency at lower temperature.
4. Programmable output voltage, current and power.
5. Operation modes: Constant Voltage(CV), Constant Current(CC) and Constant Power(CP).
6. Support CV, CC, or CP working priority setting function.
7. With internal resistance adjustment function to simulate characteristic of battery.
8. 18 bit DAC for Setting and SAR ADC for Measurement.
9. Remote sense functionality for voltage compensation.



 Operational

1. 320x240 display resolution with rotary knobs and buttons give a clear and intuitive control.
2. Patented dual-function key design for enhanced operation convenience.
3. Independent voltage and current control with rotary encoder ; adjustable digit resolution on
   panel for precise operation.
4. Two panel output adjustment modes: real-time or confirmation required.
5. Supports output ramp-up and ramp-down and slew rate control of voltage, current and power.
6. Programmable over-voltage and over-current protection.
7. Provides time-stamped operation log for traceability



 Safety

1. Intelligent speed-controlled fan to reduce acoustic noise effectively.
2. Seamless parallel stacking to save space.
3. All models are equipped with equip with auto-discharge circuit, discharge voltage to safe range
   within 10 seconds after output OFF(<60V).
4. Built-in timer allows voltage and current runtime settings and countdown function
5. Settable power-on output mode to prevents test interruption or DUT damage after power recovery.
6. Firmware upgrade via USB/LAN without opening the case; protected against power loss
7. Built-in RTC; Supports network time synchronization with user-defined NTP server and maintains
   accuracy without connection
8. CE approved.
9. ISTA 3A Vibration Test and Filled Transport Packages Test approved.



 Interface

1. Dual LAN ports as standard (LXI 1.6 compliant); interface response time as fast as 3 ms.
2. National Instruments certified IVI-C Driver provided.
3. Alarm signal output and InterLock control contacts for integration with external control systems to
   enhance operational safety.
4. SCPI compatible



 High Power/Current/Voltage Wide Range Output DC power supplies meet all Applications

✔Aerospace and Satellite Test
✔Semiconductor Equipments
✔New Energy R&D
✔Solar Cell/Array Application
✔DC to DC Convertors，DC to AC Invertors
✔Contact/Connector Testing
✔MOCVD
✔Sputtering and Coating
✔Chemical Treatment
✔Water Purification
✔Heat Processing
✔IEC 60127-1
✔Battery Testing
✔Vehicle Electronics
✔LED Testing
✔Lighting
✔Telecom and IT Industries
✔Automated Test Equipment
✔Factory Automation
✔QC Testing
✔Electronic Anti-rust
